Punch Guide Bushing of Button Dies with Double Stepped Guide Type Precision High

1. Material

Carbide / ASP23 / Vanadis4 / SKD11 / HSS / A2 / M2 / D2 / SKH51

2. Hardness
60HRC ~ 64 HRC or depends on processing materials

3. Specification

• Standards: Dayton/Lane/DIN/ISO/Fibro/Moeller/HASCO
• Tolarance : Shank Dn5 ( -0.03 ~ -0.01 mm ) , Hole P( 0 ~ 0.01 mm )
• Further dimensions, lengths and materials available on request
• Customized sizes are accepted
• Shapes: oblong, square and hexagon
• Coating service TiN, TiCN and Aitain
• Service: made-to-order and standard with stock
• Good-quality and precision
• High precison ,finishing machining
• Working speed: 180 to 220/min
• Polishing: can make close to Ra 0.4 standard is R 0.8

​

Applications:

• Punching Mold
• Automobile Die

Our Die Button product line includes:

Press Fit Style - straight and headed type with counterbored or tapered reliefs.

Ball-lock Style - available with counterbored or tapered reliefs.

EDM Blanks - are available with a wire start hole and counterbore relief, wire through hole only, or solid.

Ultra Life Styles - the industry's highest performance button, made of M-2 tool steel, including a precision machined taper relief, and offers customer specified land lengths.

Note: Our standard button tolerance is light press fit, a heavy press fit tolerance is available upon request

​

​Further Information

Packing & Delivery

Main products

• Punch - HSS punch ,Precision punch ,Ejector punch ,Punch ejector pins,Ball-lock punches, Punch retainer
• Bush -- Guide bushes , Die button
• Guide Coponents --- Guide pillars ,Guide bushings ,Guide post set ,Ball cages
• Ejectors -- Mold ejector pins ,Ejector sleeves
• Oil Free Components --- Oiless bush , Bronze Wear Plate

Spot Light of CIVADA

· Factory opened more than 12 years

· Factory Size : 1,000-3,000 square meters

· Reserch & Development Group : 8 people

· Equipment & Machine : all imported precision ones

· Good reputation in Mold Components Area.

· One-step servise for your much time and cost .

· Complete quality management system .

Civada was founded in 2004 and now has over 200 employees and two branch offices and numbers of partners.
Civada is the standard and special die components supplier in the production of special punches, guide elements and metal stamping tools. Our full line of precision metal fabricating and stamping tooling includes: guide pillars and bushes, punches, ball lock punches, retainers, die buttons (matrixes),Eector pin, Sleeve etc..

We are able to make  customised products according to international standard as well as JIS (MISUMI), DIN, AISI, FIBRO,DAYTON etc industrial standard.

Products's precision : Size tolerance within+-0.001mm, roundness within0.0015mm, surface roughness within Ra0.025,manufacturer size from 0.1mm to 6000mm .

Quality is our self-esteem.We are committed to serve our customers by continuously improving products quality and services.
